TES-1700 台湾泰仕打钉式接地电阻测试仪 摇表
TES-1700 台湾泰仕打钉式接地电阻测试仪产品介绍
中文介绍
TES-1700 是一款由台湾泰仕公司生产的打钉式接地电阻测试仪，广泛应用于电力、通信、气象、建筑等行业的接地电阻测量。该仪器具备多种功能，能够满足不同场景下的测量需求。
其主要特点包括：具有大地电压测量功能，可实现数据锁定，能够显示最大值和最小值。仪器还具备自动关机功能，当操作约三分钟后自动关闭，有效节省电源。此外，TES-1700 可进行精密的三极式测量，也可选择方便简易的二线式测量。当辅助接地钉接地电阻过高时，LCD 屏幕会显示“HΩ”警告，提醒用户注意。
在技术规格方面，TES-1700 的接地电阻测量范围为 0~3999Ω，大地电压测量范围为 0~399.9V。测量电流输出为 2mA。该仪器采用 3 3/4 位液晶显示，最大读值为 3999。其设计符合相关安全规范，确保使用安全。
TES-1700 的尺寸为 190mm×140mm×77mm，重量约为 800 克（含电池），便于携带和操作。它使用 8×1.5V 的 AA 电池供电，适合在多种环境下使用。操作温度范围为 0℃至 40℃，湿度范围为 80% RH 以下。
English Introduction
The TES-1700 is a stake-type ground resistance tester produced by Taiwan TES, widely used in industries such as power, communication, meteorology, and construction for ground resistance measurement. This instrument is equipped with multiple functions to meet the measurement needs of various scenarios.
Its main features include the ability to measure earth voltage and lock data, displaying maximum and minimum values. The TES-1700 also has an auto-shutoff function, which saves power by turning off the device after approximately three minutes of inactivity. Additionally, it can perform precise three-pole measurements as well as convenient and simple two-pole measurements. When the ground resistance of the auxiliary ground stake is too high, the LCD screen will display an "HΩ" warning to alert the user.
In terms of technical specifications, the TES-1700 has a ground resistance measurement range of 0-3999Ω and an earth voltage measurement range of 0-399.9V. The measurement current output is 2mA. The instrument features a 3 3/4-digit LCD display with a maximum readout of 3999. Its design complies with relevant safety standards to ensure safe usage.
The TES-1700 has dimensions of 190mm×140mm×77mm and weighs approximately 800 grams (including batteries), making it portable and easy to operate. It is powered by eight 1.5V AA batteries and is suitable for use in a wide range of environments. The operating temperature range is 0℃ to 40℃, with a humidity range of less than 80% RH.
TES-1700 台湾泰仕打钉式接地电阻测试仪 摇表
导通测试仪 接地引下线导通电阻测试仪 ，华谊MS2306接地直流电阻测试仪干扰电压电流频率接地摇表，DWR-Ⅲ型大型地网接地电阻测试仪，表面电阻测试仪，HB373异频接地阻抗测试仪电阻测量仪表加工定做。ETCR2100+钳形接地电阻测试仪，美国SCS CTM051 接地电阻测试仪 便携式静电接地电阻测试仪，ZC29B-1 接地电阻测试仪 ZC29B-2 指针接地摇表 避雷防雷地阻仪，SAIMEIOU333表面电阻测试仪，代替停产型号385，ETCR2000钳形接地电阻测试仪，绝缘电阻测量仪。FR2000C+/钳形接地电阻测试仪/单钳接地电阻表/环路电阻测试仪，菊水/KIKUSUI TOS6200 接地电阻测试仪，SF2678A数字接地电阻测试仪30A电阻测试仪3C认证专用，接地电阻测试仪VC4106接地摇表 数字接地仪 防雷检测仪。PROVA-5601测试仪接地电阻测试仪专用prova5601，YD9930A 程控接地电阻测试仪 常州扬子 数显接地电阻测试仪，专业 AR4105B接地电阻测试仪 接地电阻测试仪，数字式三线接地电阻表 接地电阻测试仪 ETCR3000，KYORITSU 4102A 日本共立 MODEL4102AH 接地电阻测试仪 共立4102A。
