JCW-30QA M30型模拟量线性位移传感器（中英文介绍）
产品概述
JCW-30QA M30是一款高性能非接触式线性位移检测装置，采用电磁感应原理实现位移量的精确测量。该传感器内置精密信号处理模块，能够将机械位移变化实时转换为标准模拟量信号输出，适用于工业自动化场景中对位置、行程或形变的连续监测需求。主体采用M30×1.5不锈钢螺纹结构，具备便捷安装与稳定固定特性，防护性能满足复杂工业环境要求。
核心特点
• 稳定检测性能：优化设计的电磁检测系统有效抑制环境干扰，在0~30mm量程范围内实现连续位置跟踪，重复测量一致性表现良好
• 环境适应性：全封闭式结构配合耐腐蚀材质，可在-25℃至+85℃宽温域及存在油污、粉尘的工况中保持可靠运行
• 信号兼容性：支持4-20mA/0-10V双模式模拟量输出，兼容主流PLC及控制系统的信号接入需求
• 机械耐久性：特殊处理的聚氨酯传感探头可承受轴向±3mm的机械振动，核心部件通过50万次往复运动测试验证
典型应用
本产品广泛应用于注塑机合模定位、液压缸行程控制、输送带纠偏监测、数控机床刀具补偿等场景。在冶金连铸设备中用于辊缝间距监控，在工程机械领域实现液压杆伸缩量反馈，同时适用于自动化生产线上的精密装配定位系统。
技术参数
测量范围：0-30mm（可定制）
线性精度：≤±0.5%FS
工作电压：DC12-36V宽压输入
响应频率：500Hz
防护等级：IP67（螺纹安装面）
电气接口：5芯屏蔽电缆（标准长度2m）
使用提示
建议安装时确保检测面轴向对齐，预留≥3倍探头直径的侧向避让空间。在强电磁干扰环境中推荐使用金属穿线管进行信号线屏蔽处理，长距离传输时需按规范做好信号衰减补偿。
JCW-30QA M30 Analog Linear Displacement Sensor (Bilingual Introduction)
Product Overview
The JCW-30QA M30 is a high-performance non-contact linear displacement detection device utilizing electromagnetic induction for precise displacement measurement. Equipped with an integrated signal processing module, it converts mechanical displacement into continuous analog output signals (4-20mA/0-10V), ideal for continuous position monitoring in industrial automation systems. Featuring an M30×1.5 stainless steel threaded housing, it ensures secure installation and reliable operation in challenging industrial environments.
Key Features
• Stable Detection: Advanced electromagnetic design minimizes environmental interference, delivering consistent repeatability across 0-30mm measuring range
• Environmental Resistance: Hermetic construction with corrosion-resistant materials ensures stable operation from -25℃ to +85℃ in oily/dusty conditions
• Signal Flexibility: Dual analog output modes compatible with most PLCs and control systems
• Mechanical Robustness: Polyurethane sensing probe withstands ±3mm axial vibration, validated through 500,000-cycle endurance testing
Typical Applications
Precision positioning in injection molding machines, stroke control for hydraulic cylinders, conveyor belt alignment monitoring, and CNC machine tool compensation. Widely implemented in metallurgical roll gap measurement, construction machinery cylinder feedback, and automated assembly line positioning systems.
Technical Parameters
Measuring range: 0-30mm (customizable)
Linearity: ≤±0.5% FS
Supply voltage: DC12-36V
Response frequency: 500Hz
Ingress protection: IP67 (mounting surface)
Connection: 5-core shielded cable (2m standard)
Installation Notes
Maintain axial alignment between sensor and target surface. Allow ≥3x probe diameter lateral clearance. Recommend metallic conduit for EMI protection and signal compensation for long-distance transmission.
