【中文产品介绍】
YN600.160全不锈钢压力表是一款专为严苛工业环境设计的高性能测量仪表，采用一体化全不锈钢结构，结合60°圆锥管螺纹连接技术，以稳定可靠的性能成为石油化工、机械制造、能源电力等领域的理想选择。
本产品主体采用304/316不锈钢材质，从表壳、机芯到连接部件均实现全金属密封结构，兼具高强度与耐腐蚀特性。表盘表面经哑光处理并覆盖强化玻璃视窗，可有效抵御粉尘、潮湿及化学介质的侵蚀。内部搭载精密弹簧管传感系统，通过优化设计的传动机构实现精准压力反馈，确保在-40℃至+100℃环境温度下保持±1.6%满量程的测量精度。
独特设计的60°NPT螺纹接口（可选G螺纹或M螺纹规格）实现了快速安装与密封防漏双重保障，适配DN15至DN200多种管道规格。宽幅压力测量范围覆盖0-0.6MPa至0-60MPa，满足从低压监测到高压系统的多样化需求。表体内部采用全焊接工艺消除泄漏风险，特别适用于水、油、气体及弱腐蚀性介质的长期监测。
产品内置抗振设计缓冲结构，可有效缓解设备运行中的机械振动影响，延长使用寿命。指针式表盘配备双色刻度标识，支持MPa与psi双单位显示，夜间或弱光环境下仍可清晰读取数据。建议定期检查螺纹连接密封性，避免介质结晶堵塞导压孔，使用时应确保测量压力不超过满量程的75%以保持最佳性能。
【English Product Introduction】
The YN600.160 Full Stainless Steel Pressure Gauge is an industrial-grade measuring instrument engineered for demanding operating conditions. Featuring a monobloc stainless steel construction with 60° tapered thread connections, this gauge delivers exceptional durability and measurement stability across petrochemical, mechanical manufacturing, and power generation applications.
Constructed entirely from 304/316 stainless steel, the gauge integrates metal-to-metal sealing technology from the case to the movement assembly. The matte-finished dial with reinforced glass cover provides reliable protection against dust, moisture, and chemical exposure. Its precision-engineered Bourdon tube sensing system, coupled with an optimized gear mechanism, ensures ±1.6% full-scale accuracy within an operational temperature range of -40℃ to +100℃.
The 60° NPT threaded connection (optional G-thread or M-thread variants) enables quick installation while maintaining leak-proof performance, compatible with piping systems from DN15 to DN200. With pressure measurement ranges spanning 0-0.6MPa to 0-60MPa, this welded-body design effectively eliminates leakage risks, making it suitable for long-term monitoring of water, oil, gas, and mildly corrosive media.
Vibration-damping internal structures significantly reduce mechanical oscillation impacts, extending service life. The dual-scale dial with color-coded markings displays both MPa and psi units, ensuring clear readability under low-light conditions. For optimal performance, users should periodically inspect thread seal integrity, prevent media crystallization in pressure ports, and maintain operational pressure below 75% of full scale.
