产品名称：HQSG-DGNBJQ-03T8967 智能声光报警器
（HQSG-DGNBJQ-03T8967 Intelligent Audio-Visual Alarm）
产品概述
HQSG-DGNBJQ-03T8967智能声光报警器是一款集成声音与光效双重警示功能的安全设备，适用于工业场所、公共建筑、仓储物流等场景。通过融合高频蜂鸣与高强度LED光源，设备可在复杂环境中实现快速警示响应，帮助提升现场安全管理效率。产品采用模块化结构设计，支持多角度安装适配，满足不同空间布局需求。
核心功能特性
-
多模式警示联动
设备内置6种可切换声光组合方案，包括持续警示、间歇提示、交替闪烁等模式，用户可通过物理旋钮或远程信号灵活调节。声音单元采用宽频共振技术，最大输出可达105dB，有效覆盖半径30米范围；光学警示组件搭载三色LED矩阵，支持红/蓝/白三色切换，单色亮度突破3000流明，确保在强光或昏暗环境中均能传递清晰视觉信号。
-
环境适应性设计
壳体采用工程级复合材料成型工艺，达到IP65防护等级，可在-35℃至+75℃温度区间连续工作。内部电路板经过三重防潮涂层处理，有效抵御粉尘、盐雾及弱腐蚀性气体侵蚀。底部配置通用型磁吸底座与标准螺纹接口，支持壁挂、吊装、支架固定等多种安装方式。
-
智能功耗管理
集成低功耗微处理器控制系统，待机电流低于15mA。工作状态下可根据输入信号强度自动调节能耗，配合双电路供电设计（12-24V直流/220V交流），实现不间断稳定运行。内置过载保护装置，当电压波动超过阈值时将启动自主断电机制。
应用场景
• 工业制造：设备异常报警、危险区域警示
• 物流仓储：装卸区域安全提示、紧急疏散引导
• 公共设施：消防联动报警、电梯故障提示
• 能源领域：变电站状态监测、管道压力预警
产品优势
模块化结构设计便于后期维护升级，所有功能组件均采用插拔式连接，无需专业工具即可完成部件更换。表面处理采用耐磨哑光工艺，长期使用不易产生划痕。配置智能休眠功能，非工作时段自动进入低能耗状态，延长设备使用寿命。
Product Name: HQSG-DGNBJQ-03T8967 Intelligent Audio-Visual Alarm
Product Overview
The HQSG-DGNBJQ-03T8967 intelligent audio-visual alarm integrates dual warning functions of sound and light effects, designed for industrial facilities, public buildings, and logistics storage environments. By combining high-frequency buzzing with high-intensity LED lighting, the device delivers rapid warning responses in complex scenarios, enhancing onsite safety management efficiency. Featuring modular construction, the product supports multi-angle installation configurations to accommodate diverse spatial layouts.
Core Functional Features
-
Multi-mode Alert Coordination
Equipped with 6 selectable audio-light combinations including continuous alert, intermittent reminder, and alternating flash modes. Users can adjust settings via physical dials or remote signals. The acoustic unit employs wide-frequency resonance technology with maximum output reaching 105dB, effectively covering a 30-meter radius. The optical module incorporates RGB LED arrays delivering 3000-lumen brightness per color channel, ensuring clear visual signaling in both high-ambient-light and low-visibility conditions.
-
Environmental Adaptability
The housing utilizes engineering-grade composite materials with IP65 protection rating, maintaining stable operation within -35℃ to +75℃ temperature range. The PCB undergoes triple-layer moisture-proof coating to resist dust, salt spray, and mild corrosive gases. The universal base combines magnetic adsorption with standard threaded interfaces, supporting wall-mounting, ceiling suspension, and bracket fixation.
-
Intelligent Power Management
Embedded low-power microcontroller automatically adjusts energy consumption based on input signal intensity. The dual-circuit power supply (12-24V DC/220V AC) ensures continuous operation, while overload protection activates automatic shutdown upon detecting voltage fluctuations exceeding safety thresholds.
Application Scenarios
• Manufacturing: Equipment malfunction alerts, hazardous zone warnings
• Warehouse Logistics: Loading area safety notifications, emergency evacuation guidance
• Public Infrastructure: Fire alarm linkage, elevator fault indication
• Energy Sector: Substation monitoring, pipeline pressure warnings
Product Advantages
Modular architecture simplifies maintenance and upgrades, with all functional components featuring tool-free plug-in connections. The scratch-resistant matte surface finish maintains appearance integrity through prolonged use. Smart sleep mode activates during non-operational periods to reduce energy consumption and extend service life.
