南京长盛CS2678X全数显接地电阻测试仪CS-2678X接地电阻计
产品概述
南京长盛CS2678X全数显接地电阻测试仪是一款高性能的电气安全检测设备，适用于测量各类电机、电器、仪器仪表及家用电器等设备外壳与接地线之间的电阻值。该设备采用四端测量法，可有效消除接触电阻对测试结果的影响，确保测量精度。测试过程中，仪器可同时显示测试时间、电流和电阻值，操作直观便捷。设备输出电流范围为5.0A～30A，电阻测量范围为0~600mΩ，满足不同场景下的测试需求。156
核心功能
CS2678X具备多项实用功能：测试报警值可连续任意设定，用户可根据实际需求灵活调整；可选配遥控测试枪，便于远程操作；采用高速MCU控制和高亮度荧光屏显示，确保测试数据实时可见。仪器新增开路报警功能，可直观提示测试状态是否正常。其独特的除法器电路设计能有效消除电网电压波动对测量的影响，提升测试稳定性。设备标配PLC接口，支持自动化产线集成应用。42022
技术特点
该测试仪采用正弦波输出，电流测量精度达±(5%读值+5个字)，电阻测量分为200mΩ和600mΩ两档，分辨率分别为0.1mΩ和1mΩ。测试时间可在0~999秒间设定，支持连续测试模式。仪器采用优化电路设计，对电源电压适应性强，在220V±10%电压波动范围内均可稳定工作。整机重量约15kg，结构紧凑，适合实验室和生产现场使用。51419
应用领域
CS2678X广泛应用于科研院所、计量检测机构以及电力、机械制造、家电等行业，特别适用于要求高精度测量的自动化检测场景。仪器能有效评估电气设备接地系统的可靠性，为设备安全运行提供重要数据支持。其人性化的操作界面和稳定的测试性能，使其成为电气安全检测领域的实用工具。111421
Product Overview
The Nanjing Changsheng CS2678X fully digital grounding resistance tester is a high-performance electrical safety testing device designed for measuring resistance values between equipment enclosures and grounding wires of various motors, electrical appliances, instruments, and household appliances. Utilizing a four-terminal measurement method, it effectively eliminates the influence of contact resistance on test results, ensuring measurement accuracy. During operation, the instrument simultaneously displays test time, current, and resistance values for intuitive operation. With an output current range of 5.0A～30A and resistance measurement range of 0~600mΩ, it meets diverse testing requirements.1620
Key Features
The CS2678X offers multiple practical functions: continuous adjustable alarm threshold setting allows flexible configuration according to actual needs; optional remote test gun facilitates convenient operation; high-speed MCU control and bright fluorescent display ensure real-time data visibility. The newly added open-circuit alarm function provides clear status indication. Its unique divider circuit design effectively minimizes the impact of power grid voltage fluctuations, enhancing test stability. Standard PLC interface supports automated production line integration.4522
Technical Specifications
This tester features sine wave output with current measurement accuracy of ±(5% reading +5 digits). Resistance measurement includes two ranges (200mΩ and 600mΩ) with resolutions of 0.1mΩ and 1mΩ respectively. Test duration can be set between 0~999 seconds, supporting continuous testing mode. The optimized circuit design ensures stable operation within 220V±10% voltage fluctuation range. With compact structure and approximate weight of 15kg, it s suitable for both laboratory and field applications.141920
Applications
The CS2678X is widely used in research institutions, metrology organizations, and industries including power, machinery manufacturing, and home appliances. Particularly suitable for automated testing scenarios requiring high precision, it effectively evaluates the reliability of electrical equipment grounding systems, providing critical data for operational safety. Its user-friendly interface and stable performance make it a practical tool in electrical safety testing.111421
