JDB-2-3声光报警器
JDB-2-3防爆静电接地报警器产品介绍（中英文）
中文介绍：
JDB-2-3防爆静电接地报警器是一款专为石油、化工、制药等易燃易爆环境设计的静电安全防护设备。该产品分为固定式（JDB-2）和移动式（JDB-3）两种型号，适用于加油站卸油口、加气站装卸区、化工厂液态化工品卸车场地等场所。固定式采用3米接地线+5米静电夹端线设计，适合固定作业场景；移动式配备双静电夹及5米长导线，便于移动作业。当检测到接地回路电阻超过80Ω时，设备会触发90分贝声光报警，提醒人员及时检查连接状态，确保静电有效释放。产品采用环氧树脂密封工艺，具备防腐、防水、防潮特性，内置锂电池可支持长时间连续工作，无需频繁更换电池。其破漆针采用特殊合金材质，能有效破除接触面锈蚀，保障接地可靠性。125
English Introduction:
The JDB-2-3 Anti-static Grounding Alarm is designed for hazardous environments such as petroleum, chemical, and pharmaceutical industries. It includes two models: the fixed-type (JDB-2) with a 3m grounding wire + 5m clamp cable for stationary operations, and the mobile-type (JDB-3) featuring dual clamps with 5m cables for flexible use. When the circuit resistance exceeds 80Ω, the device triggers a 90dB audible and visual alarm to prompt immediate inspection. Encapsulated with epoxy resin, it offers corrosion resistance and waterproof performance. The built-in lithium battery ensures long-term operation without frequent replacement. Its alloy-coated piercing needles effectively break through surface rust for stable grounding. Suitable for fuel depots, paint factories, and alcohol production areas, it enhances operational safety during material transfer processes.3615
产品特点与适用场景（中英文）
中文特点：
该报警器采用超低功耗设计，静态电流≤0.85mA，报警时≤3.95mA，可持续工作三年无需维护。固定式配备壁挂防雨箱体，移动式附带橡胶底座，适应-10℃~50℃工作温度范围。其声光报警功能通过集成电路实现稳定监测，无机械开关，支持24小时自动值守。特别适用于油漆厂、制药厂等需静电接地的场所，能快速响应接触不良情况，避免静电火花引发的安全隐患。2716
Key Features:
With an ultra-low power consumption design (static current ≤0.85mA), the alarm operates continuously for up to 3 years. The fixed version includes a wall-mounted rainproof casing, while the mobile version comes with rubber bases. It functions reliably within -10℃~50℃ and utilizes integrated circuits for real-time monitoring without manual switches. Ideal for environments like pharmaceutical plants and paint facilities, it instantly alerts users to poor contacts, mitigating fire risks caused by static sparks.51013
技术参数与用户价值（中英文）
中文参数：
工作电流报警时为≤3.95mA，静态≤0.85mA；报警音量达90dB（30cm距离检测）；接地夹破漆压力≥10N，确保强力接触。设备主体尺寸为240×250×120mm（固定式），移动式线缆总长10米。休眠模式下8分钟无操作自动进入节能状态，重新连接后即刻唤醒。用户可通过声光提示直观掌握接地状态，简化安全检查流程。6715
Technical Specifications:
Operating current: ≤3.95mA (alarm mode) / ≤0.85mA (standby); sound intensity reaches 90dB at 30cm. The clamps provide over 10N piercing force for reliable contact. Dimensions: 240×250×120mm (fixed-type); mobile cables total 10m. An 8-minute idle time activates sleep mode, which resumes upon reconnection. Users benefit from intuitive alerts that streamline safety checks during hazardous material handling.136
JDB-2-3声光报警器
|
接线方法
|
|
|
|
电源线 引入口(CABLE ENTRY)
|
|
|
|
|
|
1.使用防水接头或者船舶用填料函
|
|
|
2.电源线 接入口:标准规格 : PF 1/2
|
|
|
3.引入口 PF 3/4 尺寸可以定做
|
|
|
接线方法
|
|
|
1.AC交流电源产品：不用分正负极,直接连接电源.
|
|
|
2.DC直流电源产品：黑色线端子连接在负极(-)。
|
|
|
3.为了更**的连接,电源线的端部使用冷压接线端子“O"型"U"型
|
|
|
|
