声光报警器JD-7B
JD-7B 声光报警器产品介绍
中文介绍
JD-7B 声光报警器是一款性能卓越的预警设备，广泛应用于工业、商业以及公共场所的安全监控领域。它采用先进的电子技术，能够发出高分贝的警报声和强烈的光线闪烁信号，确保在复杂环境和嘈杂场景下，警报信息也能被及时、清晰地传达给相关人员。
该报警器的外观设计坚固耐用，外壳采用高强度材料制成，具备良好的抗冲击性和防护性能，能够适应各种恶劣的工作环境，如高温、低温、潮湿以及粉尘较多的场所。其内部电路经过精心设计和优化，确保了长时间稳定运行的可靠性，有效降低了因设备故障而带来的安全隐患。
JD-7B 声光报警器的操作十分简便，用户可以根据实际需求，通过简单的拨码开关或外接控制设备，轻松设置警报的触发条件和工作模式。无论是用于火灾报警、设备故障提示，还是人员安全警示等多种场景，都能快速响应并准确执行报警任务。此外，它还具备低功耗的特点，在保证报警效果的同时，能够有效降低能源消耗，为用户节省运营成本。
总之，JD-7B 声光报警器凭借其出色的性能、可靠的品质以及灵活的应用性，是保障各类场所安全的重要设备，为人们的生命财产安全保驾护航。
English Introduction
The JD-7B Audible and Visual Alarm is an outstanding warning device widely used in the fields of industry, commerce, and public places for safety monitoring. It employs advanced electronic technology to emit high-decibel alarm sounds and intense flashing light signals, ensuring that alarm information can be conveyed to relevant personnel in a timely and clear manner, even in complex environments and noisy situations.
The alarm has a robust and durable design. Its housing is made of high-strength material, providing excellent impact resistance and protective performance. It can adapt to various harsh working conditions, such as high and low temperatures, humidity, and dusty environments. The internal circuit has been carefully designed and optimized to ensure reliable long-term stable operation, effectively reducing safety hazards caused by equipment failure.
The JD-7B Audible and Visual Alarm is very easy to operate. Users can easily set the alarm trigger conditions and working modes through simple dip switches or external control devices according to actual needs. Whether it is used for fire alarms, equipment failure prompts, or personnel safety warnings in various scenarios, it can respond quickly and accurately perform the alarm task. In addition, it features low power consumption. While ensuring the alarm effect, it can effectively reduce energy consumption and save operating costs for users.
In summary, the JD-7B Audible and Visual Alarm, with its excellent performance, reliable quality, and flexible applicability, is an important device for ensuring the safety of various places and safeguarding people s lives and property.
声光报警器JD-7B
|
接线方法
|
|
|
|
电源线 引入口(CABLE ENTRY)
|
|
|
|
|
|
1.使用防水接头或者船舶用填料函
|
|
|
2.电源线 接入口:标准规格 : PF 1/2
|
|
|
3.引入口 PF 3/4 尺寸可以定做
|
|
|
接线方法
|
|
|
1.AC交流电源产品：不用分正负极,直接连接电源.
|
|
|
2.DC直流电源产品：黑色线端子连接在负极(-)。
|
|
|
3.为了更**的连接,电源线的端部使用冷压接线端子“O"型"U"型
|
|
|
|
