声光报警器FLSL-03
产品概述
FLSL-03防爆声光报警器是一款专为工业安全设计的警示设备，适用于石油、化工、燃气等存在潜在危险气体的场所。该产品通过声音和强光信号双重警示，有效提醒工作人员注意环境异常情况。报警器采用铝合金压铸外壳，结构美观且具备良好的防水防尘性能，能够抵御盐雾腐蚀和恶劣环境的影响。34
功能特点
FLSL-03防爆声光报警器具有多种实用功能：采用集成芯片设计，具备优异的电磁抗干扰性能；闪光灯内芯采用单片机特制，闪光频率可根据客户需求定制；支持多种组合配置方式，操作简便灵活。产品工作电压范围广泛，可适配AC220V/AC380V/AC24V等多种电源规格，音调和灯光颜色可根据实际需求选择。报警器工作时声级可达106分贝，确保在嘈杂环境中也能清晰识别警示信号。315
技术参数
该产品工作温度范围为-30℃至70℃，能够适应各种极端环境。外壳采用铝合金材质，灯罩为PC材料，整体重量约2.7kg，便于安装和维护。产品具有断电记忆功能，保存的设置数据不会因断电丢失。报警器提供多种语音内容选项，包括"设备启动请注意"、"皮带启动请注意"等常用警示语，也可根据实际需求定制特定语音内容。415
Product Overview
The FLSL-03 explosion-proof sound and light alarm is a safety warning device designed for industrial environments, particularly suitable for petroleum, chemical, and gas industries where hazardous conditions may exist. It provides dual warning signals through audible alarms and bright flashing lights to effectively alert personnel about abnormal situations. The housing is made of die-cast aluminum alloy with an attractive appearance and excellent waterproof/dustproof performance, capable of withstanding salt spray corrosion and harsh environmental conditions.
Key Features
The FLSL-03 alarm offers multiple practical functions: it adopts integrated circuit design with superior electromagnetic interference resistance; the flashing light core uses specially designed microcontroller units with customizable flash frequency; supports various configuration combinations for flexible operation. The product works with a wide range of voltage inputs including AC220V/AC380V/AC24V, and offers selectable tones and light colors. With sound output up to 106dB, the alarm ensures clear warning signals even in noisy environments.
Technical Specifications
This product operates within a temperature range of -30℃ to 70℃, suitable for various extreme conditions. The housing is constructed with aluminum alloy and PC material lampshade, weighing approximately 2.7kg for easy installation and maintenance. It features power-off memory function that preserves settings during outages. Multiple voice prompt options are available including "Equipment starting, please be careful" and "Conveyor starting, please be careful", with customization options for specific warning messages.
声光报警器FLSL-03
|
接线方法
|
|
|
|
电源线 引入口(CABLE ENTRY)
|
|
|
|
|
|
1.使用防水接头或者船舶用填料函
|
|
|
2.电源线 接入口:标准规格 : PF 1/2
|
|
|
3.引入口 PF 3/4 尺寸可以定做
|
|
|
接线方法
|
|
|
1.AC交流电源产品：不用分正负极,直接连接电源.
|
|
|
2.DC直流电源产品：黑色线端子连接在负极(-)。
|
|
|
3.为了更**的连接,电源线的端部使用冷压接线端子“O"型"U"型
|
|
|
|
